Cisco Small Business 200 Series

Port Management: Unidirectional Link Detection
Configuring UDLD
Cisco Small Business 200 Series Smart Switch Administration Guide 141
11
- Undetermined—The state of the link between the port and its connected port cannot be
determined either because no UDLD message was received or the UDLD message did not
contain the local device ID in it.
- Disabled—UDLD has been disabled on this port.
- Shutdown—The port has been shut down because its link with the connected device is
undetermined in aggressive mode.
• Number of Neighbors—Number of connected devices detected.
STEP 2 To modify the UDLD state for a specific port, select it and click Edit.
STEP 3 Modify the value of the UDLD state. If you select Default, the port receives the
value of the Fiber Port UDLD Default State in the Global UDLD Settings page.
STEP 4 Click Apply to save the settings to the Running Configuration file.
UDLD Neighbors
To view all devices connected to the local device:
STEP 1 Click Port Management > UDLD > UDLD Neighbors.
The following fields are displayed for all UDLD-enabled ports.
• Interface Name—Name of the local UDLD-enabled port.
• Neighbor Information:
- Device ID—ID of the remote device.
- Device MAC—MAC address of the remote device.
- Device Name—Name of the remote device.
- Port ID—Name of the remote port.
• State—State of the link between the local and neighboring device on the local port. The following
values are possible:
- Detection—The latest UDLD state of the port is in the process of being determined. Expiration
time has not yet expired since the last determination (if there was one), or since UDLD began
running on the port, so that the state is not yet determined.
- Bidirectional—Traffic sent by the local device is received by its neighbor, and traffic from the
neighbor is received by the local device.
