9.2.2.4 EXP IN connector
This male DB-15 connector is reserved for future use.
9.2.2.5 EXP OUT connector
This female DB-15 connector is reserved for future use.
9.2.3 Connecting an antenna splitter to the FS II Base station
and to
transceiver/antennas
After the connections have been made between the splitter and the
transceiver/antennas, make sure that the data LED’s are lit at the individual ports
on the antenna splitter. Also make sure that the both the green power LED and
the yellow data LED are lit on each FS II-TA. If all are properly lit, then the
connection has been successfully made and the coverage zones will be active and
will support beltpacks. If the transceiver antennas are not lit, check the
connections.
