User Guide | FreeSpeak II™ Base station version
13.3 FreeSpeak II Transceiver/Antenna
Beltpacks Supported Per
Transceiver/Antenna FSII 1.9 GHz devices: 5 in one cellular zone
FSII 2.4 GHz devices: 4 in one cellular zone
Transceiver Antenna Transmission
Range Up to 500 m (1475 ft.), line of sight
Maximum Distance, Base station to Transceiver
Via Base station Port 1,000 m (3,200 ft.) using shielded 24 AWG cable
500 m (1,600 ft) using shielded 26 AWG cable
Maximum Distance, Transceiver Powered
By Base station Port 300 m (975 ft.)
Local Powering Via 24VDC power supply
Connection to FreeSpeak Base station RJ-45
Mounting 3 fixing holes
Dimensions 50 x 140 x 175 mm (dwh)
(2.0 x 5.5 x 6.9 inches)
Weight Approx. 460g (16.1 oz).
13.4 FreeSpeak II Transceiver/Antenna Splitter
Number of Transceiver/Antennas
Supported 10
Number of Splitters Per Base station 2
Connection Between Base station
and Splitter 4-pair shielded CAT5 cable with RJ-45
Connection Between Splitter and
Transceiver/Antennas 4-pair shielded CAT5 cable with RJ-45
Powering of Splitter Locally powered via external power
supply
