Headset connector
The 4-pin male XLR-type headset socket connects to Clear-Com
headsets and other headsets with 4-pin female connectors. This
headset connector is for the on-board two-channel intercom, with
controls just to the right of the connector.
Headset channel A talk control/listen control
The channel A talk switch and associated light, and listen level
encoder, allow full-duplex conversations with any FS II wireless
beltpacks or other communications systems wired to the rear of the
Base station to which the on-board Channel A has been assigned.
Assignments are done via the front-panel programming.
The talk switch is momentary/latching, such that pressing it and
holding down will create a talk path that ends when the user releases
the switch, while quickly tapping it will latch the talk, and a second
tap will release it. The LED lights red when a talk is active.
Turning the listen level encoder clockwise will allow the user to hear
the other party’s voice, increasing the level to maximum when fully
clockwise.
The channel B talk switch and associated light, and listen level
encoder, function the same as the controls for Channel A.
These are channel A and channel B enable switches.
If the switch is held in for more than 8 seconds autonulling mode will
be enabled for the current partyline and the following message will
be displayed:
