User Guide | FreeSpeak II™ Base station version
Page 93
Key to beltpack bottom connectors
Feature
Description
Headset socket (7-pin XLR–M)
Pin
Function
1
Mic ground
2
Mic +
3
Ground
4
Left Headphone Output
5
Right Headphone Output
6
PTT1
7
PTT2/Headset detect
Table 15: Headset socket pin out
D
3.5 mm stereo jack.
E
Micro USB connector.
Table 16 Key to beltpack bottom connectors
