Codan NGT 2012 RF User Manual

13 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05266-001 - Audio I/F PCB
BOM Revision
Date Valid On
D4 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D5 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D6 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D7 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D8 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D9 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D10 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
G1 Cell, Lithium 3V, 35mAh PCB
Mtg
National Semiconduct BR1225-1VD 65-71000-002 1
H1 LED, Tricolour T-1 3/4
Diffused
Liteon LTL-52RG 65-61110-901 1
IC1 Switch, Analog Quad Fast
SOIC16
Harris DG445DY YI-00445-700 1
IC2 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC3 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC4 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC5 Tcvr, CAN bus
SOIC8
Philips PCA82C250T YI-82250-700 1
IC6 Switch, Analog Quad Fast
SOIC16
Harris DG445DY YI-00445-700 1
IC7 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC8 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC9 Reg, Voltage +10V LVD 1A
TO263_3
National Semiconduct LM2940S-10 XB-02940-700 1
IC10 Reg, Voltage +5V 1A
TO263_3
National Semiconduct LM7805S XB-07805-701 1
IC11 EPLD prgmd, RFU Audio Codan 90-20588-001 90-20588-001 1
IC12 Micro prgmd, RFU Audio I/O Codan 90-20591-001 90-20591-001 1
IC13 Clock/Calendar/RAM IIC Bus
SOIC8
SGS Thomson MK41T56S00TR YK-04156-700 1
IC14 MOSFET, high side switch 4A
SOT426
Philips BUK207-50Y BUK207-50Y 1
IC15 Comparator, Quad O/C Output
SOIC14
National Semiconduct LM339M XD-00339-700 1
IC16 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
K1 Relay, 2C 9V Ltch SMD 2x579
Ohm
Matsushita TQ2SL-L2-9V 64-21225-258 1
L1 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L2 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L3 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
Page 4 of 9
