Codan NGT 2012 RF User Manual

13 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05266-001 - Audio I/F PCB
BOM Revision
Date Valid On
L5 Ind, Common Mode 5.5A Taiyo Yuden CMO8RA20 43-80001 1
L6 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L7 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L8 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L9 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L10 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L11 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L12 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L13 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L14 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L15 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L16 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L17 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L18 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
P2 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
P3 Header (P) 26way 2row Boxed
Fix
Thomas & Betts 609-2627 60-00260-000 1
P4 Not Fitted Codan **-00000-001 99-00000-001 1
P5 Not Fitted Codan **-00000-001 99-00000-001 1
P6 Header (P) 8way 2mm Latch
Fixed
AMP 292161-8 60-00080-001 1
P7 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
R1 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R2 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R3 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R4 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R5 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R6 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R7 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R8 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R9 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R10 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R11 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R12 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R13 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
Page 5 of 9
