Codan NGT 2012 RF User Manual

13 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05266-001 - Audio I/F PCB
BOM Revision
Date Valid On
R14 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R15 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R16 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R17 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R18 0 Ohm Jumper 1206 Philips 2322 711 90001 40-00001-101 1
R19 0 Ohm Jumper 1206 Philips 2322 711 90001 40-00001-101 1
R20 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R21 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R22 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R23 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R24 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R25 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R26 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R27 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R28 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R29 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R30 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R31 18k Ohm 5% 0,125W 1206 Philips 2322 711 61183 40-41800-101 1
R32 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R33 18k Ohm 5% 0,125W 1206 Philips 2322 711 61183 40-41800-101 1
R34 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R35 18k Ohm 5% 0,125W 1206 Philips 2322 711 61183 40-41800-101 1
R36 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R37 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R38 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R39 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R40 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R41 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R42 10 Ohm 5% 0,125W 1206 Philips 2322 711 61109 40-11000-101 1
R43 10 Ohm 5% 0,125W 1206 Philips 2322 711 61109 40-11000-101 1
Page 6 of 9
