Codan NGT 2012 RF User Manual

12 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
IC402 Buffer, Hex Inverting Schmitt
SOIC14
Philips HEF40106BT YG-40106-700 1
IC403 Direct digital synthesiser
SSOP28
Analog Devices AD9850BRS YL-09850-700 1
IC404 Direct digital synthesiser
SSOP28
Analog Devices AD9850BRS YL-09850-700 1
IC405 Micro prgmd, RFU RF/IF I/O Codan 90-20592-001 90-20592-001 1
J1 Socket, Coax Mini Low Prof
Fixed
Taiko Denki TMP-J02X-A1 60-19390-002 1
J2 Socket, Coax Mini Low Prof
Fixed
Taiko Denki TMP-J02X-A1 60-19390-002 1
K101 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K201 Not Fitted Codan **-00000-001 99-00000-001 1
K202 Not Fitted Codan **-00000-001 99-00000-001 1
L101 Ind, 4,7uH 10% 4532 Taiyo Yuden LEM4532T4R7K 43-80470-000 1
L102 Ind, 10uH 10% 3225 TOKO 380KB-100K 43-81100-001 1
L103 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L104 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L105 Ind, 220nH 20% 4532 Taiyo Yuden LEM4532TR22M 43-80022-000 1
L106 Ind KoilKraft 44-70490 44-70490 1
L107 Ind, 470nH 20% 4532 Taiyo Yuden LEM4532TR47M 43-80047-001 1
L108 Ind, 220nH 20% 4532 Taiyo Yuden LEM4532TR22M 43-80022-000 1
L109 Ind, 4,7uH 10% 4532 Taiyo Yuden LEM4532T4R7K 43-80470-000 1
L110 Ind, 45MHz roofing filter Codan 44-70452 44-70452 1
L111 Ind, 45MHz roofing filter Codan 44-70452 44-70452 1
L112 Ind, 4,7uH 10% 4532 Taiyo Yuden LEM4532T4R7K 43-80470-000 1
L113 Ind, 330nH 20% 4532 Taiyo Yuden LEM4532TR33M 43-80033-000 1
L114 Ind KoilKraft 44-70490 44-70490 1
L115 Ind, 390nH 20% 4532 Taiyo Yuden LEM4532TR39M 43-80039-001 1
L116 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L117 Ind, 45MHz roofing filter Codan 44-70452 44-70452 1
L118 Ind, 4,7uH 10% 4532 Taiyo Yuden LEM4532T4R7K 43-80470-000 1
L119 Ind, 100nH 20% 3225 TOKO 380NB-R10M 43-80010-000 1
L201 Ind, 1mH 10% 1812 Coilcraft 1812LS-105XKBC 43-83100-000 1
L202 Ind, 1mH 10% 1812 Coilcraft 1812LS-105XKBC 43-83100-000 1
L203 Ind, 1mH 10% 1812 Coilcraft 1812LS-105XKBC 43-83100-000 1
L204 Ind, 1mH 10% 1812 Coilcraft 1812LS-105XKBC 43-83100-000 1
L205 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L206 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L207 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L401 Ind, 10uH 10% 3225 TOKO 380KB-100K 43-81100-001 1
L402 Ind, Common Mode 1.5A Taiyo Yuden CM05RA06 43-80000 1
L403 Ind, VCO Protran 44-70488 44-70488 1
L404 Ind, 10uH 10% 3225 TOKO 380KB-100K 43-81100-001 1
L405 Ind, Common Mode 1.5A Taiyo Yuden CM05RA06 43-80000 1
L406 Ind, Common Mode 1.5A Taiyo Yuden CM05RA06 43-80000 1
L407 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L408 Ind, 10uH 10% 3225 TOKO 380KB-100K 43-81100-001 1
L409 Ind KoilKraft 44-70492 44-70492 1
L410 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L411 Ind, 120nH 5% 3028 Coilcraft 1008CS-121XJBB 43-80012-000 1
L412 Ind, 330nH 10% 3028 Coilcraft 1008CS-331XKBC 43-80033-001 1
L413 Ind, 330nH 20% 4532 Taiyo Yuden LEM4532TR33M 43-80033-000 1
Page 10 of 21
