Codan NGT 2012 RF User Manual

12 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
P1 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
P201 Header (P) 4way 1row Molex 22-03-2041 60-00041-100 1
P401 Not Fitted Codan **-00000-001 99-00000-001 1
R101 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R102 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R103 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R104 8,2k Ohm 5% 0,125W 1206 Philips 2322 711 61822 40-38200-101 1
R105 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R106 68 Ohm 5% 0,125W 1206 Philips 2322 711 61689 40-16800-101 1
R107 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R108 220 Ohm 5% 0,125W 1206 Philips 2322 711 61221 40-22200-101 1
R109 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R110 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R111 150 Ohm 5% 0,125W 1206 Philips 2322 711 61151 40-21500-101 1
R112 150 Ohm 5% 0,125W 1206 Philips 2322 711 61151 40-21500-101 1
R113 220 Ohm 5% 0,125W 1206 Philips 2322 711 61221 40-22200-101 1
R114 22 Ohm 5% 0,125W 1206 Philips 2322 711 61229 40-12200-101 1
R115 22 Ohm 5% 0,125W 1206 Philips 2322 711 61229 40-12200-101 1
R116 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R117 220 Ohm 5% 0,125W 1206 Philips 2322 711 61221 40-22200-101 1
R118 68k Ohm 5% 0,125W 1206 Philips 2322 711 61683 40-46800-101 1
R119 82k Ohm 5% O,125W 1206 Philips 2322 711 61823 40-48200-101 1
R120 82k Ohm 5% O,125W 1206 Philips 2322 711 61823 40-48200-101 1
R121 3,9k Ohm 5% 0,125W 1206 Philips 2322 711 61392 40-33900-101 1
R122 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R123 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R124 82k Ohm 5% O,125W 1206 Philips 2322 711 61823 40-48200-101 1
R125 330 Ohm 5% 0,125W 1206 Philips 2322 711 61331 40-23300-101 1
R126 150 Ohm 5% 0,125W 1206 Philips 2322 711 61151 40-21500-101 1
R127 3,9k Ohm 5% 0,125W 1206 Philips 2322 711 61392 40-33900-101 1
Page 11 of 21
