Codan NGT 2012 RF User Manual

05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03905-002 - Dual Line Equaliser PCB
BOM Revision
Date Valid On
R213 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R214 270k Ohm 2% 0,4W MF
Res
Philips 2322 181 54274 40-52700-500 1
R215 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R216 47k Ohm 5% 0,33W CF
Res
Philips 2322 211 13473 40-44700-020 1
R217 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R218 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R219 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R220 270k Ohm 2% 0,4W MF
Res
Philips 2322 181 54274 40-52700-500 1
R221 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R222 150k Ohm 5% 0,33W CF
Res
Philips 2322 211 13154 40-51500-020 1
R223 33k Ohm 5% 0,33W CF
Res
Philips 2322 211 13333 40-43300-020 1
R224 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R225 8,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13822 40-38200-020 1
R226 47k Ohm 5% 0,33W CF
Res
Philips 2322 211 13473 40-44700-020 1
R227 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R228 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R229 330k Ohm 5% 0,33W CF
Res
Philips 2322 211 13334 40-53300-020 1
R230 39k Ohm 5% 0,33W CF
Res
Philips 2322 211 13393 40-43900-020 1
R231 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R232 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R233 8,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13822 40-38200-020 1
R234 56k Ohm 5% 0,33W CF
Res
Philips 2322 211 13563 40-45600-020 1
R235 Not Fitted Codan **-00000-001 99-00000-001 1
R236 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R237 330k Ohm 5% 0,33W CF
Res
Philips 2322 211 13334 40-53300-020 1
R238 120k Ohm 2% 0,4W MF
Res
Philips 2322 181 54124 40-51200-500 1
R239 130k Ohm 2% 0,4W MF
Res
Philips 2322 181 54134 40-51300-500 1
R240 130k Ohm 2% 0,4W MF
Res
Philips 2322 181 54134 40-51300-500 1
R241 Not Fitted Codan **-00000-001 99-00000-001 1
R242 Not Fitted Codan **-00000-001 99-00000-001 1
