Codan NGT 2012 RF User Manual

05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03905-002 - Dual Line Equaliser PCB
BOM Revision
Date Valid On
R243 4,7k Ohm 5% 0,33W CF
Res
Philips 2322 211 13472 40-34700-020 1
R244 47k Ohm 5% 0,33W CF
Res
Philips 2322 211 13473 40-44700-020 1
R245 15 Ohm 5% 0,33W CF
Res
Philips 2322 211 13159 40-11500-020 1
R246 15 Ohm 5% 0,33W CF
Res
Philips 2322 211 13159 40-11500-020 1
T1 Txfr Protran 44-30821 44-30821 1
T2 Txfr Protran 44-30821 44-30821 1
V1 Transistor, NPN Si Philips BC548 BC548 1
V2 Transistor, NPN Si Philips BC548 BC548 1
