InteliDrive DCU Industrial 3.4.0 Global Guide
39
2 – 1
Analog/Binary Input for display and buttons backlit control. Connect resistive pot for continuous
backlit change: 0Ω ~ 0%; 2400Ω ~ 100%. Or just place contact to switch between 0% and 100%
intensity.
Note: It is possible to connect up to five InteliVision 5 CAN or four InteliVision 8 displays to common CAN2
bus. The display addresses must be different in this case.
4.1.11 InteliVision 8, InteliVision 8 Marine
