InteliDrive DCU Industrial 3.4.0 Global Guide
89
6 Communication
6.1 InteliDrive – Engine ECU communication
6.1.1 Example of standard J1939 engine
List of possible J1939 analog data that can be configured to received in ID-DCU Industrial.
Name Unit
Engine speed RPM
Actual torque %
Demand torque %
Coolant temp °C
EngineOil temp °C
Boost Pressure bar
Intake Manifold Temp °C
Air Intake pressure bar
Exhaust Gas Temp °C
Accelerator Pedal position %
Percent Load %
Fuel Rate L/h
EngOil Filter Diff.Press bar
Battery Potential (Voltage) V
Fuel Delivery Pressure bar
Engine Oil level %
Crankcase Pressure bar
Coolant Pressure bar
Coolant Level %
Fault reset = accepts (confirms) diagnostic message = removes inactive message form ECU Alarm list only
when ECU Alarm list is visible.
Note: Fault reset button is “screen sensitive”. It is active only on selected actual controller screen.
6.1.2 Tier 4 Final/StageV
Tier 4 Final/StageV support generally provides monitoring and control of after-treatment system installed on
generators engine. The requirements are defined as:
Providing After-Treatment status information by
displaying universal lamps (icons)
displaying analog and binary values
