InteliDrive DCU Industrial 3.4.0 Global Guide
76
PLC Function Selection Available Number of available blocks in ID-DCU Industrial 3.4.0
Ana Switch 16x
Force Hist 4x
Force Prot 16x
Jump 8x
Mux Const. 4x
Counter 16x
Decomp 8x
Convert 16x
3D Map 2x
5.2.3 PLC configuration example
Let suppose a diesel compressor. The engine speed is controlled via ID-SCM Speed governor analog output (no
data communication). InteliDrive measures output pressure.
