9. To install a new expansion card, hold the card just above the expansion socket on the system
board then move the card toward the rear of the chassis so that the bottom of the bracket on the
card slides into the small slot on the chassis. Press the card straight down into the expansion
socket on the system board.
Figure 7-19 Installing an Expansion Card
NOTE: When installing an expansion card, press firmly on the card so that the whole
connector seats properly in the expansion card slot.
10. Replace the slot cover retainer by sliding the tab on the top of the retainer behind the chassis
frame (1) then rotating the retainer into place (2).
Figure 7-20 Installing the Slot Cover Retainer
Expansion Cards
95
