Memory/Optical Drive Cover
Description Spare part number
Memory/optical drive cover 623382-001
The memory/optical drive cover allows access to memory, the optical drive, the rear metal cover, and
the rear cover.
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer
on page 106).
2. Remove the five black Phillips PM 2.5x6.0 screws (1) that secure the cover to the computer.
3. Lift the bottom of the memory/optical drive cover at the slots, and then lift the cover off the
computer (2).
Figure 8-1 Removing the memory/optical drive cover
To replace the cover, reverse the removal procedures.
Memory/Optical Drive Cover
107
