Rear Metal Cover
Description Spare part number
Rear metal cover not spared
The rear metal cover provides access to the hard drive, system board, fan sink, display cable, stand
bracket, and display panel. The rear metal cover is securing with three screws.
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer
on page 106).
2. Remove the stand (see
Stand on page 111).
3. Remove the hinge cover (see
Hinge Cover on page 112).
4. Remove the memory/optical drive cover (see
Memory/Optical Drive Cover on page 107).
5. Remove the rear cover (see
Rear Cover on page 113).
6. Remove the rear metal cover by removing the three Torx 2.5x6.0 screws that secure the cover
to the computer.
Figure 8-12 Rear metal cover screw locations
118 Chapter 8 Removal and Replacement Procedures All-in One (AIO) Chassis
