Compaq 100eu - All-in-One PC User Manual

Display Panel
Description Spare part number
Display panel (20 in; 508 mm) 623384-001
The display panel is secured to the display enclosure by 13 tabs on all sides of the panel.
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer
on page 106).
2. Remove the stand (see
Stand on page 111).
3. Remove the hinge cover (see
Hinge Cover on page 112).
4. Remove the memory/optical drive cover (see
Memory/Optical Drive Cover on page 107).
5. Remove the rear cover (see
Rear Cover on page 113).
6. Remove the rear metal cover (see
Rear Metal Cover on page 118).
7. Remove the display cable (see
Display Cable on page 126).
8. Remove the system board (see
System Board and I/O Board Assembly on page 127).
9. Remove the stand bracket (see
Stand Bracket on page 132).
10. The display panel is secured with 13 clips, as follows:
●
4 on the right side
●
4 on the left side
Display Panel
133
