Expansion Cards
Description Spare part number
Expansion card not spared
The computer has one standard low-profile PCI Express x1 expansion slot.
Figure 7-15 Expansion Slot Location
To remove, replace, or add an expansion card:
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 77).
2. Remove the access panel (
Access Panel on page 78).
3. Remove the front bezel (
Front Bezel on page 79).
4. Remove the optical drive (
Removing an Optical Drive on page 87).
92 Chapter 7 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
