Front Bezel
Description Spare part number
Front bezel 622198-001
The front bezel is held in place with two tabs.
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 77).
2. Remove the access panel (
Access Panel on page 78).
3. Lift up the two tabs on the left side of the bezel (1), then pull the bezel off the chassis (2).
Figure 7-2 Removing the Front Bezel
To reinstall the front bezel, reverse the removal procedure.
Front Bezel
79
