Front Bezel
Description Spare part number
Front bezel 622203-001
Bezel blank 622199-001
The front bezel is held onto the computer with three tabs.
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 43).
2. Remove the access panel (
Access Panel on page 44).
3. Press outward on the three latches on the right side of the bezel (1), then rotate the right side of
the bezel off the chassis (2) followed by the left side.
Figure 6-2 Removing the Front Bezel
4. To remove the a bezel blank, gently twist and pull on the bezel blank until it breaks free from the
front bezel. Replacement bezel blanks are available using spare part number 622199-001
NOTE: The appearance of the front bezel may vary.
To reinstall the front bezel, reverse the removal procedure.
Front Bezel
45
