Webcam module
Description Spare part number
Webcam module 631756-001
Webcam cable 631754-001
The webcam module is mounted in a bracket located on the top of the computer (viewed from the
back). The bracket is held in place using two screws.
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer
on page 106).
2. Remove the stand (see
Stand on page 111).
3. Remove the hinge cover (see
Hinge Cover on page 112).
4. Remove the memory/optical drive cover (see
Memory/Optical Drive Cover on page 107).
5. Remove the outer rear cover (see
Rear Cover on page 113).
6. Remove the two PM 2.0x5.0 screws that secure the webcam bracket to the computer.
Figure 8-8 Removing the webcam module
7. Lift the bracket enough to gain access to the cable connector, and the disconnect the cable from
the module.
114 Chapter 8 Removal and Replacement Procedures All-in One (AIO) Chassis
