5. Slide the new SODIMM into the socket at approximately a 30° angle (1) then press the SODIMM
down (2) so that the latches lock it in place.
Figure 7-5 Installing a SODIMM
NOTE: A memory module can be installed in only one way. Match the notch on the module
with the tab on the memory socket.
A SODIMM must occupy the XMM1 (top) socket.
6. Replace the SODIMM in the DIMM1 socket if it was removed.
The computer automatically recognizes the additional memory when you turn on the computer.
Memory Module
85
