Compaq Deskpro EN Series of Personal Computers A-9
Table A-15
AGP Connector
Pin Signal "B" Signal "A" Pin Signal "B" Signal "A"
1 Spare 12v 34 VDDQ3.3 VDDQ3.3
2 5V SPARE 35 AD21 AD22
3 5V RESERVED 36 AD19 AD20
4 USB+ USB- 37 GND GND
5 GND GND 38 AD17 AD18
6 INTB# INTA# 39 C/BE2# AD16
7 CLK RST# 40 VDDQ3.3 VDDQ3.3
8 REQ# GNT# 41 IRDY# FRAME#
9 VCC3.3 VCC3.3 42
10 ST0 ST1 43 GND GND
11 ST2 RESERVED 44
12 RBF# PIPE# 45 VCC3.3 VCC3.3
13 GND GND 46 DEVSEL# TRDY#
14 SPARE SPARE 47 VDDQ3.3 STOP#
15 SBA0 SBA1 48 PERR# GND
16 VCC3.3 VCC3.3 49 GND GND
17 SBA2 SBA3 50 SERR# PAR
18 SB_STB RESERVED 51 C/BE1# AD15
19 GND GND 52 VDDQ3.3 VDDQ3.3
20 SBA4 SBA5 53 AD14 AD13
21 SBA6 SBA7 54 AD12 AD11
22 KEY KEY 55 GND GND
23 KEY KEY 56 AD10 AD9
24 KEY KEY 57 AD8 C/BEO#
25 KEY KEY 58 VDDQ3.3 VDDQ3.3
26 AD31 AD30 59 AD STB0 RESERVED
27 AD29 AD28 60 AD7 AD6
28 VCC3.3 VCC3.3 61 GND GND
29 AD27 AD26 62 AD5 AD4
30 AD25 AD24 63 AD3 AD2
31 GND GND 64 VDDQ3.3 VDDQ3.3
32 ADSTB1 RESERVED 65 AD1 AD0
33 AD23 C/BE3# 66 SMB0 SMB1
