Concept Pro VXH960-4 - Display Settings - OSD

32
OSD
You can set the Camera Name, Icon, Status Bar, Timeline, Borderline, User
Name and Language.
1. From <SYSTEM SETUP> - <DISPLAY>, select <OSD>.
2. Use the [pqtu/ENTER] buttons on the remote control or use the
mouse to set each option of the OSD item.
> CAMERA TITLE: specify the display of the camera title on the
screen.
> RECORDING MODE ICON: specify the display of the record mode
icon on the screen.
> STATUS BAR ON FULL SCREEN MODE: select to show or hide
the status bar in full screen mode.
- AUTO HIDE: place the cursor in the lower area of the screen to
display the status bar. If moving the cursor up, the status bar will
disappear.
- ALWAYS ON: The status bar will be displayed at all times.
- 5 SEC ~1 MIN: If there is not any mouse movement from 5
seconds to 1 minute, the status bar will disappear.
> TIMELINE ON FULL SCREEN MODE: select to show or hide the
timeline in full screen mode.
- AUTO HIDE: place the cursor in the right corner to display
the timeline. If moving the cursor to the left, the timeline will
disappear.
- ALWAYS ON: The timeline will be displayed at all times.
- ALWAYS OFF: The timeline will not be displayed.
> BORDER LINE: specify the display of the border between
channels in a split mode
> BORDER COLOUR: select a colour for the border.
> USER NAME: specify the display of the currently logged-in users
on the status bar.
> LANGUAGE: select a menu display language.
3. To apply the change, click <APPLY> in the bottom of the screen.
4. When done, press the [EXIT] button on the remote control or click
<CLOSE> in the lower screen. The con rmation message appears and
you will return to the previous menu.
You can con gure the display settings regarding the OSD menus, monitor
and sequence settings.
Display Settings
