CTH200 Series PLC User Manual
107
< 1ms(I0.3, I0.7)
Connection of 2 Wire
Proximity Sensor (Bero)
Permissible leakage current
1mA
Isolation (Field to Logic)
Optical Isolation (Galvanic)
Yes
500 VAC for 1 minute
HS input rate
HSC Logic 1=16~26 VDC
200KHz(single/dual phase) (I0.0, I0.4)
200KHz (A/B phase) (I0.0 & I0.1, I0.4 & I0.5)
(Input Wave shape ratio 40%~60%)
Number of inputs on
simultaneously
All
Cable length
Shield
500m for standard input, 50m for HSC (using shielded
twisted pair for HSC and ground the shield)
Unshielded
300m for standard input
HSC max commutating
frequency
50KHz
General
Transistor output
Output counts
8
Type
Solid – MOSFET(drain)
Rated voltage
24 VDC
Output voltage range
5~28.8 VDC
Surge current (max)
8A for 100ms
Logic 1(max)
0.5V
Logic 0(min)
VCC-0.5V
Rated current per point
(max)
0.5A
Rated current per common
(max)
2.0A
Leakage current (max)
10μA
lighting load (max)
3.5W
Sensing clamp voltage
L+ - 48 VDC, 1W power
On resistance
Typical 0.3 Ω (max 0.6Ω)
Isolation
Optical Isolation (Galvanic)
Isolation groups
500 VAC, 1 minute
Refer to the wiring diagrams below
Delay (max)
Off to On
On to Off
0.2μs(Q0.0, Q0.1, Q0.2, Q0.3), 50μs(Q0.4, Q0.5, Q0.6,
Q0.7)
0.2μs(Q0.0, Q0.1, Q0.2, Q0.3), 130μs(Q0.4, Q0.5, Q0.6,
Q0.7)
Pulse frequency (max)
200KHz(Q0.0, Q0.2)
Outputs on simultaneously
All at 55°C
Two outputs parallel
Yes, only for outputs in the same group
Cable length
Shield
500m
