COTRUST CTH200 Series User Manual

CTH200 Series PLC User Manual
3
 Integrated parameter self-tuning fuzzy logic algorithm and temperature control PID library,
with high accuracy and dynamic performance
 Build-in plenty of integrated functions with simplified programming and flexible control
 High-speed closed loop can be delivered to support some high-speed system application
 Abundant motion control functions, suitable for some synchronization and positioning
applications
High speed and high-capacity
 Logical operation speed: 0.22µs for H224 and H226L ; 0.15µs for H224X/H226XL/H228XL
 Floating-point calculation speed: 12µs for H224/H226L; 8µs for H224X/H226XL/H228XL
 Large program capacity: 12K-72Kbyte
 Large data space: 8K-110Kbyte
 High-speed Input counter: 4 for H224 and H226L; 6 for H224X/H226XL/H228XL
 High speed pulse output: 3 for H224 and H226L; 2 for H224X/H226XL/H228XL
Ultra system expandation
 Analog I/O: 32AI/32AQ for H224/H226L; 194AI/194AQ for H224X/H226XL/H228XL
 Digital I/O: 128DI/128DQ for H224/H226L; 640DI/640DQ for H224X/H226XL/H228XL
 Expansion I/O modules up to 7
1.2 Expansion Modules
CTH200 CPU offers local I/Os, you can also use expansion modules for more additional I/Os and
communication functions. The various expansion modules include digital I/O modules, analog
I/O modules, temperature collection modules and DP communication modules etc. These
modules consist of different I/O number, used for configuring various scale of I/Os with high cost
performance. All modules are installed with standard DIN35 rail.
Table 1-2 Specifications of expansion modules
Specifications
Order number
SM221 digital input module, 8 inputs, 24VDC
CTH2 221-1BF32
SM221 digital input module, 16 inputs, 24VDC
CTH2 221-1BH32
SM221 digital input module, 32 inputs, 24VDC
CTH2 221-1BL32
SM222 digital output module, 8 transistor outputs, 24VDC, 0.5A(with
Output Protection)
CTH2 222-1BF32
SM222 digital output module, 16 transistor outputs, 24VDC, 0.5A(with
Output Protection)
CTH2 222-1BH32
SM222 digital output module, 32 transistor outputs, 24VDC, 0.5A(with
Output Protection)
CTH2 222-1BL32
SM222 digital output module, 8 relay outputs, 2A
CTH2 222-1HF32
SM222 digital output module, 16 relay outputs, 2A
CTH2 222-1HH32
SM223 digital input/output module, 4*24VDC inputs, 4 transistor outputs,
CTH2 223-1BF32

COTRUST CTH200 Series Specifications

General

Brand	COTRUST
Model	CTH200 Series
Category	Controller
Language	English
