CTH200 Series PLC User Manual
95
4.7 Communication Module Specifications
Table 4-7-1 Communication modules Order info
Modules
Order No.
SM277A Profibus DP slave interface module, 12M, optoelectronic
isolation
CTH2 277-0AA32
SM277B Profibus DP slave module, 1.5M, optoelectronic isolation
CTH2 277-0AB32
SM277C CAN slave module, with 8DI/6DO, optoelectronic isolation,
expand to 7 modules
CTH2 277-0AC32
Both SM277A and SM277B adopt photoelectric isolation technology, with high reliability and
strong anti-interference ability. These two modules are equipped with terminal resistance, bus
connection, no need for special network connector. Its power supply has the function of reverse
connection protection and surge absorption, and can be used in harsh working environment.
However, SM277A needs to cooperate with the CPU, while SM277B can be used as a
standalone slave station with six extension modules, the scale of slave station I/O up to
128DI/128DO, 48AI/24AQ.
4.7.1 SM277A DP Slave Interface Module Specifications
Table 4-7-2 SM277A modules specifications
General
Order No.
CTH2 277-0AA32
Dimension (W×H×D)
71.3 × 96 × 62mm
Port number
1
Electric interface
Isolated RS485
Native I/O
0
Max expansion modules
6
PROFIBUS-DP/MPI
baud rate (auto setting)
9.6/19.2/45.45/93.75/187.5/500Kbps; 1/1.5/3.6/12Mbps
Protocol
PROFIBUS-DP and MPI
LED
OFF
Red
Flash Red
Green
DX MODE
Not in data
exchange mode
--
--
In data
exchange mode
DP ERROR
No error
Leave the data
exchange
mode
parameterize/
configuration
error
--
POWER
No 24V power
--
--
24VDC power
normal
CPU FAULT
Good health
Internal fault
--
--
Cable length (Max)
< 93.75Kbps
1200m
187.5Kbps
1000m
500Kbps
400m
1 ~ 1.5Mbps
200m
