SM 277C status LED can be used to diagnose the CANopen master-slave network.
Switch on the power of SM 277C, “ON” LED (Green) for the power would light on. If the BF and
SF LED remain OFF, indicate the SM 277C works normal, on or flash mean fault in hardware
configuration or wiring. If the main system running well, see table below for the reason for error:
Table 4-7-10 Function of SM 277C LED lights
LED
ON
OFF
FLASH
Note
ON
Normal power
No power
---
Power indicator
SF
Expansion I/O
module fault
Expansion I/O module
no fault
---
System Fault
BF
CAN network not
detected
CAN network detected
Inconsistent
configuration
Bus Fault
4.7.4 SM277-PN Slave Module Specifications
Table 4-7-11 Specifications of SM277-PN module
Features
Dimension(W×H×D)
71×80×62 mm
Power consumption
Rated input voltage
24V DC
Input voltage range
20.4V~28.8V DC
Input current
0.8A
Power voltage of bus
+5V DC
Power current of bus
1.1A
Isolation
External power is isolated from system power
Power protection
Reverse-connection protection and surge absorption
LED lights features
24V power light(green)
ON = 24VDC power supply normal
OFF = No 24VDC power supply
SF indicator light(red)
ON = Expansion I/O bus or PROFINET module malfunction
OFF = No error
BF indicator light(red)
ON = PROFINET bus communication error (not connect with switch,
no Internet detected)
Blinking = different configuration
OFF = No error
MT indicator light(yellow)
(maintenance)
ON = Synchronization lost
OFF = No error
P1R/P2R port indicator
light (green)
ON = With connection to switch /PN master station
OFF = No connection to switch /PN master bus
P1R/P2R port indicator
light(yellow)
ON = With data transceiver to /PN master bus
OFF = No data transceiver to switch /PN master bus
Table 4-7-12 Specifications of SMS277-PN module
Expansion I/O specifications
Max modules numbers
each slave bus support
8(digital modules, analog modules, temperature modules and PID
control modules, except other type modules)
