COTRUST CTH200 Series - Diagrams of CPU Structure and Wiring

Technical Specifications
36
25
0
Port 1: receive character
26
0
Port 1: transfer complete
36
0
Module diagnostics interrupt
Disperse
(Medium
Priority)
0
1
Rising edge, I0.0
2
1
Rising edge, I0.1
4
1
Rising edge, I0.2
6
1
Rising edge, I0.3
1
1
Falling edge, 10.0
3
1
Falling edge, I0.1
5
1
Falling edge, I0.2
7
1
Falling edge, I0.3
12
1
HSC0 CV=PV
27
1
HSC0 direction change
28
1
HSC0 External recovery/Zphase
13
1
HSC1 CV=PV
14
1
HSC1 direction change
15
1
HSC1 External recovery
16
1
HSC2 CV=PV
17
1
HSC2 direction change
18
1
HSC2 External recovery
19
1
PTO 0 complete interrupt
20
1
PTO 1 complete interrupt
32
1
HSC3 CV=PV
29
1
HSC4 CV=P
30
1
HSC4 direction change
31
1
HSC4 External recovery/Z phase
33
1
HSC5 CV=PV
Timer
(Lowest priority)
10
2
Timer interrupt 0
11
2
Tmer interrupt 1
21
2
Timer T32 CT=PT interrupt
22
2
Timer T96 CT=PT interrupt
4.2.2 Diagrams of CPU Structure and Wiring
PLC structure
