CTH200 Series PLC User Manual
109
resolution, 1*12bits voltage/current output resolution
EBH-AMS-06 Analog I/O Expansion Board,4*12bits voltage
resolution, 2*12bits voltage output resolution
CTH2 AMS-06S1-EB
EBH CAN master communication Expansion Board, 1Mbps,
optoelectronic isolation
CTH2 CAN-01S1-EB
4.10.1 Analog Expansion Board Specifications
Analog Expansion Board EBH-AMS-03/EBH-AMS-06 can be used with CTH200 modules by
invoking in the CTH200_CPU expansion slot.
Table 4-10-2 Analog Expansion Board I/O specifications
Items
Specifications
EBH-AMS-03
EBH-AMS-06S1
EBH-AMS-06S2
Features
Dimension (W
×
H
×
D)
24
×
14.4
×
68.2mm
Voltage supply
+5VDC
Current
60mA
200mA
LED
Power LED
Health status of power: ON - 5VDC normal, OFF - no power
SF LED
Calibration status, FLASH - calibration failure
Analog input
Power supply
5VDC, output current < 200mA
Counts
2
4
Type
Single-end voltage input
Range
±10V
Data word format for
full-scale
-32000 to +32000
DC input impedance
>100KΩ
Max input voltage
30VDC
Resolution
11 bits + 1 sigh bit
Isolation
None
Accuracy
Worst case (0-55
゜
)
±2.5% full scale
Typical (25
゜
)
±1.0% full scale
Repeatability
±0.05% full scale
Conversion time from analog
to digital
125ms
Transform principle
Σ-Δ
Step response
Max 250ms
Noise suppression
Typical -20dB@50Hz
Analog output
Counts
1
2
Signal range
Voltage 0-10V
--
Current 0-20mA
--
Current 0-20mA
