COTRUST CTH200 Series User Manual

Power Budget
162
7.2 5VDC Power
Table 7-1 5VDC power consumption table
CPU and DP module
5VDC current offered
for expansion IO (mA)
Expansion
module
5VDC current
(mA)
CPU H224/H224X
H226L/H226XL/H228XL
SM277B/SM277C
SM277PN
660
660
660
1100
SM 221-1BF
57
SM 221-1BH
79
SM 221-1BL
179
SM 222-1BF
57
SM 222-1BH
79
SM 222-1BL
174
SM 222-1HF
68
SM 222-1HH
115
SM 223-1BF
57
SM 223-1BH
73
SM 223-1BL
115
SM 223-1HF
58
SM 223-1PH
89
SM 223-1PL
150
SM 231-0HC
87
SM 231-0HF
87
SM 231-1HF
87
SM 231-5HF
87
SM 232-0HB
87
SM 232-0HD
87
SM 235-0KD
87
SM 231-7PB
87
SM 231-7PC
87
SM 231-7PD
87
SM 231-7PF
87
SM 231-7TD
87
SM 231-7TF
87
SM 231-7HF
87
SM 231-7ND
87
SM 231-7NF
87
SM 231-7WA
140
SM 277A
70
SM 253 motion
control module
90
Calculate max I/O configuration of CTH200 system according to the above table, refer to Chapter
7.4 Power Calculation Example
