COTRUST CTH200 Series User Manual

Appendix
320
Definition of lights status
Lights
OFF
FLASH
ON
RUN light(green)
---
Loading program
Normal
SF light
Normal
Error
---
SMB101
Left times can be used(including this time), display 255 if there is no limit.
Flash frequency: about 0.5s(accuracy is not required)
※ Limit of using times for programming card
You can set the limit of using times for programming card, which minus one every time the
uploading complete.
Steps:
Steps 1: When PLC is under “programming card download mode”, set limit of using times by
using SM100 and display at SMB101 position before download first block in MicroWIN
Steps 2: The limit of using times for programming card minus one every time the uploading
complete(including the third time of uploading failure).
Parameter definition
Value
Explanation
0
No limit
1-255
Times available
Default
0
O Battery Card and Memory Card
CTH200 PLC equip with specific battery card, and the high-performance series CPU
(H224X/H226XL/H228XL) support memory card.
Table O-1 Order info
Type
Description
Order No.
Memory card
64K(user program, recipe and data record)
CTS7 291-MC064
256K(user program, recipe and data record)
CTS7 291-MC256
Battery card
Data-hold time: 200d, typical
CTH2 291-8BA33
Steps to change battery card or memory card:
1) Unplug the battery cover in power cut off.
2) Take down the existing battery card in vertical direction to avoid damaging slot.
3) Insert the new battery card into slot and cover the cap.
Backup the data before cut the PLC power off to change the battery.
