COTRUST CTH200 Series User Manual

Technical Specifications
26
4 Technical Specifications
CTH200 series PLC and the expansion modules enjoys different specifications.
4.1 General Specifications
Table 4-1-1 Electrical and environmental specifications
Items
Description
Rated input voltage
AC: 220V, DC: 24V
Voltage range
AC: 85 V~265 V, DC: 20.4 ~ 28.8V
Operation
temperature
0 ~ 55℃
Storage temperature
-25 ~ 70 ℃
Ventilation
Inlet Air 50.8 mm below unit
Humidity
5 ~ 95% (non-condensing)
Electrical Interference
Pulse width 50ns, repetition frequency 5kHz, 2,000V voltage
peak
Vibration
Frequency 10~57Hz, amplitude 0.1mm, acceleration 1.0g, 10
times each dimension
Impact resistance
15g for 11ms, 3 times at 3 dimensions
High voltage
insulation
Terminal to ground 2200VDC, I/O port to other terminal
1500VAC, dwell time 1 minute
Ground connection
Type 3 (single point grounding with multi-branch)
Operating
environment
Dust proof, Noncorrosive environment
Toppling
100 mm, 4 drops, unpacked
Free Fall
1 m, 5 times, packed for shipment
4.2 CPU
4.2.1 CPU Specifications
This section introduces the whole general specifications for CTH200 PLC, including Inputs,
Outputs and Power Supply.
Table 4-2-1 Performance specifications of CTH200 PLC
Items
Description
H224/H226L
H224X/H226XL
H228XL
Dimension(W×H×D)
137×96×71.3mm
196.5×96×71.3mm
200×100×69.5mm
