COTRUST CTH200 Series User Manual

CTH200 Series PLC User Manual
309
L Instruction Set
Table L-1 CTH200 instruction set
Bit logic instruction
LD
Normally open contact load
instruction
LD SM0.0
ALD
AND load instruction
ALD
A
Normally open contact AND
instruction
A SM0.0
OLD
OR load instruction
OLD
O
Normally open contact OR
instruction
O SM0.0
LPS
Logic into stack instruction
LPS
LDN
Normally close contact load
instruction
LDN SM0.0
LDS
Load stack instruction
LDS 1
AN
Normally close contact AND
instruction
AN SM0.0
LRD
Logic read instruction
LRD
ON
Normally close contact OR
instruction
ON SM0.0
LPP
Logic out stack instruction
LPP
LDI
Normally open contact
immediately load instruction
LDI I0.0
=
Output instruction
= Q0.0
AI
Normally open contact AND
immediately instruction
AI I0.0
=I
Immediately output instruction
=I Q0.0
OI
Normally open contact OR
immediately instruction
OI I0.0
S
Set instruction
S Q0.0 1
LDNI
Normally close contact
immediately load instruction
LDNI I0.0
SI
Immediately set instruction
SI Q0.0 1
ANI
Normally close contact AND
immediately instruction
ANI I0.0
R
Reset instruction
R Q0.0 1
ONI
Normally close contact OR
immediately instruction
ONI I0.0
RI
Immediately reset instruction
RI Q0.0 1
NOT
Logic stack top revere
instruction
NOT
AENO
Power flow AND instruction
AENO
