COTRUST CTH200 Series User Manual

Technical Specifications
110
Data word format for
full-scale
0 to +32000
Resolution
12bits
LSB value
Voltage 5.00μA
--
Voltage 5.00μA
Current 2.50mV
--
Isolation
None
Accuracy
Worst case (0-55
゜
)
Voltage ±3% full-scale
--
Current
±
2% full
scale
--
Current
±
2% full
scale
Typical (25
゜
)
Voltage ±1% full scale
--
Current
±
1% full
scale
--
Current
±
1% full
scale
Settling time
 Resistive load
 Capacitive load
 Inductive load
0.1ms
0.2 ms
3.3 ms
0.5 ms(1mH)
Max output drive
Voltage ≥5000Ω
Current ≤500Ω
Terminal definition
1. Schematic and terminal diagrams for AMS-03 are shown in the following figures. Table
following give the definition of each terminal.
Table 4-10-3 AMS-03 Terminal definition
Terminal
Signal definition
Terminal
Signal definition
1
Float
5
Analog Input A+
2
Voltage output VO
6
Analog Input B+
3
Current output IO
7
Ground GND-M
4
Ground GND-M
8
Earth
2. Schematic and terminal diagrams for AMS-06 are shown in the following figures
