CTH200 Series PLC User Manual
5
200KHz, 2xPTO/PWM outputs, 200KHz, COTRUST motion control
libraries
SM277A Profibus DP Slave Interface Module, 12M traffic rate,
photoelectric isolated
CTH2 277-0AA32
SM277B Profibus DP Slave module, 1.5Mbps traffic rate, photoelectric
isolated
CTH2 277-0AB32
SM277C CAN Slave module, 8DI/6DO, photoelectric isolated, up to 7
extendable modules
CTH2 277-0AC32
Table 1-3 BD Expansion Boards
Module Name
Specifications
Order number
EBH AMS-03
Analog I/O Expansion Board, 2*12 bits precision
inputs, 1*12 bits precision voltage/current output
CTH2 AMS-03S1-EB
EBH-AMS-06
Analog I/O Expansion Board, 4*12 bits precision
voltage inputs, 2*12 bits precision voltage output
CTH2 AMS-06S1-EB
EBH-AMS-06
Analog I/O expansion board, 4*12 bits precision
voltage inputs, 2*12 bits precision current output
CTH2 AMS-06S2-EB
EBH CAN-01
CAN Master communication expansion board,
1Mbps, photoelectric isolated
CTH2 CAN-01S1-EB
EBH PWM04
Charging guidance expansion board, two-channel
voltage input, single-channel PWM output.
CTH2 PWM-04S1-EB
Notice
H224/H226L do not support CAN-01 master expansion board.
Features of expansion modules:
Filter technology
All the analog modules integrate CPU itself, with high stability due to advanced filter technology.
Digital module
All the digital I/O modules are equipped with optoelectronic isolation and disturbance rejection.
Temperature acquisition module
Integrated bus isolation, power isolation and interchannel isolation, high immunity from
interference and high sampling accuracy, with intelligent fault diagnosis.
Intelligent module
The PID modules like Temperature Control can promote the respond speed of program
executing.
Communication module
The expansion board for CAN master and the DP Slave module can significantly increase the
interconnectivity and communication performance.
Analog I/O expansion board
