COTRUST CTH200 Series User Manual

Product Overview
8
DC input short-interrupt
and voltage change
IEC61000-4-29
Short-interrupt: 10ms
Voltage change: 80%~120%, 100ms
Antidumping vibration
wave
IEC61000-4-12
Power line: 1KV
Digital I/O(0(24V or higher): 1KV
EMC – conduction and radiated emission
Radiation(noise) EMI
EN55011, type A 1 group
Measuring distance: 10m
30MHz~230MHz, < 40dB(uV/m) peak value
230MHz~1000MHz, < 47dB(uV/m) peak value
Conduction(noise) AC
power interference
EN55011, type A 1 group
Measuring distance: 10m
0.15~0.5MHz, < 79dB(uV/m)peak value;< 66dB(uV/m) average
0.5~5MHz, < 73dB(uV/m)peak value;< 60dB(uV/m) average
5~30MHz, < 73dB(uV/m)peak value;< 60dB(uV/m) average
Environment test index
Hot operation
IEC60068-2
Cold operation
IEC60068-2
60℃ 16h
-10℃ 16h
Hot startup IEC60068-2
Cold startup IEC60068-2
60℃ 2h
-10℃ 2h
Hot/cold cycle operation
IEC60068-2
3h of dwell time under -10℃~60℃, temperature rising speed 1℃
/min, 2 cycles
Hot storage IEC60068-2
Cold storage IEC60068-2
70℃ 72h
-40℃ 72h
Hot/cold shock
IEC60068-2
3h of dwell time under -40 ℃ ~70 ℃ , temperature changing
time<1min, 5 cycles
Hot and humid
IEC60068-2
40℃ 48h
Alter hot and humid
IEC60068-2
25℃~55℃ 95%, 2 cycles
Sine vibration(bare
machine) IEC60068-2
5~150Hz, 0.05G
2
/Hz
150Hz~500Hz -3dB/oct, 1 hour/axis; X, Y and Z 3 axes in all
Strike (bare
machine)IEC60068-2
15G, 11ms pulse, 3 times/direction
Hybrid gas erosion test
IEC60068-2-60
H2S: 0.1ppm, NO2: 0.2ppm, CL2: 0.02ppm, temperature: 30℃,
humidity: 75%, period: 4 days
High-press insulation test index
24V/5V standard circuit
110V/220V circuit to earth
110V/220V circuit
110V/220V to 24V/5V
circuit
500 VAC
1500 VAC
1500 VAC
1500 VAC
