CTH200 Series PLC User Manual
173
with pulses, or only execute during the first cycle.
Parameter
address
Explanation
Type
Value range
Note
Mode
Select communication
protocol: Input 1 defines
Port as the Modbus protocol
and enables it, and 0
defines Port as the PPI and
disables Modbus protocol.
Bit
Addr
Set site address
Byte
1~247
Baud
Set baud rate
DWord
1.2K, 2.4K,
4.8K, 9600,
19.2K, 38.4K,
57.6K, 115.2
Parity
Set parity
Byte
0—No parity
1—Odd parity
2—Even parity
All settings use
one stop bit.
Delay
Extends standard Modbus
information end timeout
condition by increasing the
specified number of ms for
the standard Modbus
information timeout.
Int
0~32767
Unit: ms
MaxIQ
Set available I and Q.
Int
0~128
0 means forbid
I/O read and
write
Recommend
MaxIQ 128, allow
to ask all IO of
CTH200.
MaxAI
Sets the number of word
input registers (AI).
Int
0~32
0 means forbid
read analog
input.
Recommend
MaxAI value:
H224/H224X-32
H226L/H226XL-32
/H228XL-32
MaxHold
Sets the number of available
V storage word hold
registers.
Int
0~32767
Unit: Word
HoldStart
Sets the starting address of
the available holding
register in the V storage
area.
DWord
Pointer point to
V memory
Done
When the MBUS INIT
instruction completes, the
Done output is on.
Bit
Error
Error output byte contains
the result of the execution of
the instruction.
Byte
※ MBUS_SLAVE instruction
MBUS_SLAVE instruction is used to service requests from the Modbus master station and must
be executed every cycle in order to check and respond to Modbus requests. When EN input
switch on, it execute each cycle without input parameters.
