CTH200 Series PLC User Manual
313
TODW VB0
TODWX VB0
Shift cycle instruction
SLB
Left shift byte
SLB VB0, 4
RLW
Left rotation Word
RLW VW0, 8
SLW
Left shift Word
SLW VW0, 8
RLD
Left rotation double Word
RLD VD0, 16
SLD
Left shift double Word
SLD VD0, 16
RRB
Right rotation byte
RRB VB0, 4
SRB
Right shift byte
SRB VB0, 4
RRW
Right rotation Word
RRW VW0, 8
SRW
Right shift Word
RRD
Right rotation double Word
RRD VD0, 16
SRD
Right shift double Word
SRD VD0, 16
SHRB
Shifting register bit instruction
SHRB I0.0, V0.0, 8
RLB
Left rotation byte
RLB VB0, 4
--
--
Logic calculate instruction
INVB
Reverse byte instruction
INVB VB0
ORB
OR byte instruction
ORB 1, VB0
INVW
Reverse Word instruction
INVW VW0
ORW
OR Word instruction
ORW 10000, VW0
INVD
Reverse double Word
instruction
INVD VD0
ORD
OR double Word instruction
OD 100000, VD0
ANDB
AND byte instruction
ANDB 1, VB0
XORB
XOR byte instruction
XORB 1, VB0
ANDW
AND Word instruction
ANDW 10000, VW0
XORW
XOR Word instruction
XORW 10000, VW0
ANDD
AND double Word
instruction
ANDD 100000, VD0
XORD
XOR double Word instruction
XORD 100000, VD0
Counter instruction
CTU
Count-up instruction
CTU C1, 10000
HDEF
HSC definition
HDEF 0, 0
CTD
Count-down instruction
CTD C1, 10000
HSC
HSC instruction
CTUD
Count down and up
instruction
CTUD C1, 10000
PLS
Pulse output instruction
Timer instruction
TON
Open delay timer
TON T37, 10000
BITIM
Read start timer
BITIM VD0
TONR
Reserved open delay timer
TONR T31, 10000
R_UTIM
Read current microsecond
value instruction
TOF
Turn off delay timer
CITIM
Calculate interval timer
