COTRUST CTH200 Series User Manual

Appendix
332
SMB110 to SMB111: programming card upload control
SMB110 to SMB111 Use for programming card load control:
SM address
Function description
SMB110
Start enforcing load protection function
SMB111
Programming card cover item:
0 – Cover programming block and data block; 1 – Not cover
programming block, cover data block
2 - Cover programming block, not cover data block; 3 - Not cover
programming block and data block
4 – Same when ADD is 0
SMB114 to SMB115: expansion board information
SMB114: Expansion board module type
SMB114 = 0x20: CAN
0x19: 2AI/1AQ
0x1E: 4AI/2AQ
Detailed description is shown in the following table:
Bti7
Bti6
Bti5
Bti4
Bti3
Bti2
Bti1
Bti0
E
TT
t
II
OO
E
If there is
module
1: Module do not exist
0: Module exist
TT
(module
type)
00
Non intelligent module
01
Intelligent module
10
Special non intelligent module(7PF)
11
cotrust intelligent module(PID)
t
(module
subtype)
Non
intelligent
module
0: Digital
1: Analog
Intelligent
module
0: Normal intelligent
1: Cotrust intelligent module(PID)
II(inputs)
Non
intelligent
module
00
No input
01
AI/8DI
10
2AI/16DI
11
4AI/32DI
Intelligent
module
Reserved
OO
(outputs)
Non
intelligent
module
00
No output
01
1AO/8DO
10
2AO/8DO
11
4AO/32DO
Intelligent
module
Reserved
