COTRUST CTH200 Series User Manual

Technical Specifications
60
Table 4-4-9 Quick reference of address based on formula above:
VWxx
channel0
channel 1
channel 2
channel 3
channel 4
channel 5
channel 6
channel 7
Slot 0
VW0
VW2
VW4
VW6
VW8
VW10
VW12
VW14
Slot 1
VW64
VW66
VW68
VW70
VW72
VW74
VW76
VW78
Slot 2
VW128
VW130
VW132
VW134
VW136
VW138
VW140
VW142
Slot 3
VW192
VW194
VW196
VW198
VW200
VW202
VW204
VW206
Slot 4
VW256
VW258
VW260
VW262
VW264
VW266
VW268
VW270
Slot 5
VW320
VW322
VW324
VW326
VW328
VW330
VW332
VW334
Slot 6
VW384
VW386
VW388
VW390
VW392
VW394
VW396
VW398
Table 4-4-10 SM231-5HF specifications
Features
Dimension (W×H×D)
71.3 × 96 × 62mm
LED
24V power , ON: normal, OFF: faulted
Power
+5VDC Consumption
87mA
L+
50mA
L+ Coil Voltage
20.4~28.8VDC
Power consumption
2.5W
Analog Input
Counts
8
Isolation (field to logic)
Opto-couplers isolation, 500V AC for 1 minute
Type
Differential
Signal range
Voltage (Unipolar)
0~10V, 0~5V
Voltage (Bipolar)
±2.5V (channel 0~7)
Current
0~20mA (channel 6~7)
Data word format
Unipolar
0~32000
Bipolar
-32000~32000
Resolution, full-scale
Voltage (Unipolar)
2.5mV (0~10V range); 1.25mV(0~5V range)
Voltage (Bipolar)
2.5mV(±5V range); 1.25mV(±2.5V range)
Analog to digital
conversion time
Approx. 10ms
Conversion time for 8
channels
100ms
Common mode rejection
40dB, DC - 60Hz
Common mode voltage
-12V≤ Signal voltage plus common mode voltage ≤+12V
DC Input impedance
Voltage ≥2MΩ
Current 250Ω
Maximum input voltage
30VDC
Maximum input current
32mA
