MAC Parameter
SMAC Filter: The type of source MAC address. Select “Any” to allow all types of source MAC addresses or select “Specific”
to define a source MAC address. (This field is for ARP and Ethernet frame type only.)
DMAC Filter: The type of destination MAC address.
Any: To allow all types of destination MAC addresses
MC: Multicast MAC address
BC: Broadcast MAC address
UC: Unicast MAC address
Specific: Use this to self-define a destination MAC address. (This option is for Ethernet frame type only.)
Ethernet Type Parameter
Ether Type Filter: This option can only be used to filter Ethernet II formatted packets. Select “Specific” to define an Ether
Type value.
ARP Parameter
ARP/RARP: Specify the type of ARP packet.
Any: No ARP/RARP opcode flag is specified
ARP: The frame must have ARP/RARP opcode set to ARP,
RARP: The frame must have ARP/RARP opcode set to RARP
Other: The frame has unknown ARP/RARP opcode flag
Request/Reply: Specify whether the packet is an ARP request, reply, or either type.
Any: No ARP/RARP opcode flag is specified
Request: The frame must have ARP Request or RARP Request opcode flag set.
Reply: The frame must have ARP Reply or RARP Reply opcode flag set.
Sender IP Filter: Specify the sender’s IP address.
Any: No sender IP filter is specified.
Host: Specify the sender IP address.
Network: Specify the sender IP address and sender IP mask.
Target IP Filter: Specify the destination IP address.
Any: No target IP filter is specified.
Host: Specify the target IP address.
Network: Specify the target IP address and target IP mask.
