Step Action
5 Insert the R, C, and optional L syringes into the respective channels of the
rotating block.
6 Secure the syringes to the cartridge by doing one of the following:
a. Syringes with Luer fittings: Twist the syringe to engage the Luer connec-
tion.
NOTICE
Do
not tighten the Luer connection too much. Tight-
ening the connection too much can damage the
syringe and the cartridge.
b. Syringes without Luer fittings: Push the syringe until you meet resist-
an
ce.
NOTICE
Do
not insert the syringe too far. Inserting the syringe
too far can damage the syringe and the cartridge.
7 Close the lid of the instrument.
8 Tap P
RIME
at the bottom left of the user interface.
Result:
The syringe pushers travel approximately 6 mm after detecting a syringe,
which is equivalent to:
• approximately 0.1 mL when using a 1 mL syringe, or
6 Operation
6.
3 Run a procedure
6.3.5 Prepare the cartridge
NanoAssemblr Ignite and Ignite+ Operating Instructions NIN1134 AA 92
