Dahua DHI-NVR608R-64-4KS2 User Manual

85
channel name. means camera is online. means camera is offline.
 In case the channel amount has exceeded the device max split amount, the edit view
interface can display the max screen number amount and current screen number. In Figure
3-63, click or , switch the video from other channel.
Figure 3-63
Step 2 On the edit view interface, drag the channel to the desired window, or drag on the preview
window to switch the position.
Check the channel number at the right bottom corner to view the current channel sequence. See
Figure 3-64.

Dahua DHI-NVR608R-64-4KS2 Specifications

General

Model	DHI-NVR608R-64-4KS2
Operating System	Embedded LINUX
IP Camera Input	64 channels
Two-way Talk	Yes
OSD	Yes
Video Detection and Alarm	Yes
Wireless	No
USB	2 x USB 2.0
Operating Humidity	10% to 90% (non-condensing)
Video Compression	H.265+/H.265/H.264+/H.264
Video Output	HDMI, VGA
Alarm input	16 channel
Relay Output	4
Ethernet	2 RJ-45 port (10/100/1000Mbps)
Internal HDD	8 SATA interfaces, up to 10TB each
eSATA	1
RS232	1
RS485	1
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	-10°C to +55°C
Dimension	440mm
Weight	6.5 kg
