80 • Operational Reference Linea Lite GigE Series Camera
Trigger Delay TriggerDelay Specifies the delay to apply after receiving the trigger and
before activating triggerEvent. The delay can be set in
microseconds.
Beginner
Rotary Encoder Output
Mode
rotaryEncoderOutputMode Specifies the conditions for the Rotary Encoder interface to
generate a valid Encoder output signal.
Expert
DFNC
Position Position
On the camera, the "position" behaviour exists, but the
number of counts is small (7-bits / 128 counts). The
encoder can reverse for 256 ticks and then go forward and
behave as expected for "position" style behaviour. If the
user exceeds 256 ticks, the count will max out, but will not
reset. When the user starts going forward again, 256 lines
will be dropped / ignored and then resume output.
Motion Motion
The triggers are generated for all motion increments in
either direction.
Rotary Encoder Direction rotaryEncoderDirection Specifies the phase which defines the encoder forward
direction.
Expert
DFNC
Clockwise Clockwise Inspection goes forward when the rotary encoder direction
is clockwise (phase B is ahead of phase A).
Counter Clockwise CounterClockwise
Inspection goes forward when the rotary encoder direction
is counter clockwise (phase A is ahead of phase B).
Rotary Encoder Input A
Source
rotaryEncoderInputASource Selects which input line to assign to the rotary encoder
input A (also known as shaft encoder). Note that the Line
Mode feature must be set to Input. The list of supported
input line sources is device-specific.
Expert
DFNC
Line 1
Line1
Line 1 is assigned to the Rotary Encoder Input A.
Line 3 Line3 Line 3 is assigned to the Rotary Encoder Input A.
Rotary Encoder Input B
Source
rotaryEncoderInputBSource
Selects which input line to assign to the rotary encoder
input B
(also known as shaft encoder). Note that the Line
Mode feature must be set to Input. The list of supported
input line sources is device-specific.
Expert
DFNC
GND GND Rotary Encoder Input B is not used
Line 2
Line2
Line 2 is assigned to the Rotary Encoder Input B
Rotary Encoder Source
Activation
rotaryEncoderSrcActivation
Specifies the signal edge(s) use to increment the rotary
encoder.
Expert
DFNC
Rising Edge RisingEdge
The rotary encoder uses the rising edge of the source
signal.
Any Edge AnyEdge The rotary encoder uses either the rising edge or falling
edge of the source signal.
Rotary Encoder Rescaler
Order
rotaryEncoderRescalerOrder Specifies the order that the multiplier and divider are
applied.
Guru
DFNC
Multiplier Divider multiplierDivider The signal is multiplied before been divided.
Divider Multiplier dividerMultiplier The signal is divided before been multiplied.
Rotary Encoder Multiplier rotaryEncoderMultiplier Specifies a multiplication factor for the rotary encoder
output pulse generator.
Beginner
DFNC
Rotary Encoder Divider rotaryEncoderDivider
Specifies a division factor for the rotary encoder output
pulse generator.
Beginner
DFNC
Rotary Encoder Position rotaryEncoderPosition Displays the relative positions of rotary encoder inputs A
and B.
Guru
DFNC
Input A ahead B SrcA Input A is ahead of Input B.
Input B ahead A SrcB Input B is ahead of Input A.
