Linea Lite GigE Series Camera Operational Reference 81
Line Selector
LineSelector Selects the physical line (or pin) of the external device
connector to configure.
Beginner
Line 1 Line1
Index of the physical line and associated I/O control block
to use. Pin 1 and Pin 2 is the RS-422 Input Port 1+, 1-,
respectively.
Line 2 Line2
Index of the physical line and associated I/O control block
to use. Pin 3 and Pin 4 is the RS-422 Input Port 2+ and 2-
, respectively.
Line 3 Line3 Index of the physical line and associated I/O control block
to use. Pin 6 and Pin 7 is the Port 3+ and 3-, respectively.
Line 4 Line4
Index of the physical line and associated I/O control block
to use. Pin 11 and Pin 12 is Output Port 4+ and 4-,
respectively.
Line 5 Line5 Index of the physical line and associated I/O control block
to use. Pin 13 and Pin 14 is the Output Port 5+ and 5-,
respectively.
Line Format LineFormat
Specify the current electrical format of the selected
physical input or output. Applies to all physical lines. (RO)
Expert
RS422 RS422 The line accepts or sends RS422 level signals.
Open Collector OpenCollector The line is an output line configured as an open collector.
Line Mode LineMode Reports if the physical Line is an Input or Output signal.
(RO)
See Input Signals Electrical Specifications.
See Output Signals Electrical Specifications.
Expert
Input Input The line is an input line.
Output Output The line is an output line.
Line Status LineStatus
Returns the current status of the selected input or output
line. (RO)
Expert
False / True
Line Inverter LineInverter Controls whether to invert the polarity of the selected
input or output line signal.
Beginner
False / True
Input Line Detection Level lineDetectionLevel
Specifies the voltage threshold required to recognize a
signal transition on an input line.
Expert
DFNC
Threshold for TTL Threshold_for_TTL
A signal below 0.8V will be detected as a Logical LOW and
a signal greater than 2.4V will be detected as a Logical
HIGH on the selected input line.
Input Line Debouncing
Period (in μs)
lineDebouncingPeriod Specifies the minimum delay before an input line voltage
transition is recognized as a signal transition.
Beginner
DFNC
Line Electrical Termination
lineElectricalTermination Controls if the electrical termination of both Line 1 and 2 is
enabled or disabled.
Expert
DFNC
Disabled
Disabled Line termination is disabled.
Enabled
Enabled Line termination is enabled.
