82 • Operational Reference Linea Lite GigE Series Camera
Output Line Source
outputLineSource Selects which internal signal or event driven pulse or
software control state to output on the selected line. Note,
the Line Mode feature must be set to Output. The List of
supported output line sources is product-specific. The
Event Control section provides details and timing diagrams
for the supported trigger modes.
DFNC
Off Off Line output is Open
Software Controlled SoftwareControlled The Output Line Value feature changes the state of the
Generate a pulse on the start of the Frame Active event
Pulse on: Start of Line PulseOnStartofLine Generate a pulse on the start of the Line Active
Pulse on: Start of Exposure
Generate a pulse on the Exposure Start event. This option
is typically used to trigger a strobe light.
Pulse on: Rejected Trigger PulseOnInvalidTrigger Generate a pulse on the Invalid Trigger event.
Pulse on: End of Exposure
Generate a pulse on the Exposure End event. This option
is typically used to trigger a strobe light.
Pulse on: Valid Line Trigger
Generate a pulse on the LineTrigger event.
Pulse on: Invalid Line
Trigger
PulseOnInvalidLineTrigger Generate a pulse on the Invalid LineTrigger event.
Pulse on: End of Timer 1 PulseOnTimer1End Generate a pulse on the TimerEnd 1 event.
Pulse on: End of Counter 1 PulseOnCounter1End Generate a pulse on the CounterEnd 1 event.
Pulse on: Input 1 Signal PulseOnInput1 Generate a pulse on the Input signal 1 event
Generate a pulse on the Input signal 2 event
Output Line Pulse Signal
Activation
outputLinePulseActivation Specifies the input line activation mode to trigger the
Output Line pulse.
DFNC
Rising Edge RisingEdge
Specifies that the trigger is considered valid on the rising
edge of the source signal.
Falling Edge FallingEdge Specifies that the trigger is considered valid on the falling
edge of the source signal.
Any Edge AnyEdge Specifies that the trigger is considered valid on the falling
or rising edge of the source signal.
Output Line Pulse Delay outputLinePulseDelay
Sets the delay (in µs) before the output line pulse signal.
Applicable for the Output Line Source
feature. Note, the
LineMode feature must be set to output.
DFNC
Output Line Pulse Duration outputLinePulseDuration Sets the width (duration) of the output line pulse in
DFNC
Output Line Value outputLineValue Sets the output state of the selected Line if the
outputLineSoftwareLatchControl = OFF.
Output Line
Source must be Software Controlled. If the
outputLineSoftwareLatchControl = Latch , the state of the
pin will change with the Output Line Software Command
DFNC
Active Active Sets the Output circuit to close
Inactive Inactive Sets the Output circuit to open
Line Status All LineStatusAll
Returns the current status of all available line signals, at
time of polling, in a single bit field. The order is Line 1, 2,
3, ... (RO)
Output Line Software
Command
outputLineSoftwareCmd Writing a value of 1 in the bit field applies the Latch value
of the outputLineSoftwareLatchControl and/or executes
the PulseOnSoftwareCmd for any output line programmed
for software control. The feature outputLineSoftwareCmd
can take any binary value and each bit set to 1
corresponds to a Icommand for an Output.
Bit-0 is Line 3,
Bit-1 is Line 4,
Bit-2 is Line 5,
Bit-3 is Line 6
This is applicable to
Output Line Source = Pulse On: where
Software Cmd (for Pulse mode) or OutputLineSource =
Software Controlled and OutputLineSoftwareLatchControl
= Latch (for static states).
DFNC
