86 • Operational Reference Linea Lite GigE Series Camera
Activation
counterIncrementalLineActivation Selects the counter signal activation mode for line inputs.
The counter increments on the specified signal edge or
DFNC
Rising Edge RisingEdge
Increment the counter on the rising edge of the selected
Falling Edge FallingEdge
Increment the counter on the falling edge of the selected
I/O Line.
Any Edge AnyEdge Increment the counter on the falling or rising edge of the
selected I/O Line.
Counter Reset Source
counterResetSource
Selects the signal source to reset the counter then waits
for the next countStartSource signal or event.
Expert
DFNC
Reset Cmd Off Reset on reception of the Reset Icommand.
Acquisition Start AcquisitionStart Reset on reception of the Acquisition Start.
Acquisition End AcquisitionEnd Reset on reception of the Acquisition End.
Exposure Start ExposureStart Reset on reception of the Exposure Start event.
Exposure End ExposureEnd Reset on reception of the Exposure End event.
Frame Trigger FrameStart Reset on reception of the Frame Trigger (valid or invalid)
Valid Frame Trigger ValidFrameTrigger Reset on reception of the Valid Frame Trigger event.
Reset on reception of the Invalid Trigger event.
Line 1 Line1
Reset counter on the specified transition on line 1.
See Input Signals Electrical Specifications.
Line 2 Line2 Reset counter on the specified transition on line 2.
Reset on reception of the Timer 1 End.
Counter 1 End Counter1End Reset on the reception of the Counter 1 end.
Counter Reset Input Line
Activation
counterResetLineActivation Specify the edge transition on the selected line that will
reset the selected counter.
DFNC
Rising Edge RisingEdge Reset counter on rising edge of the selected signal.
Falling Edge FallingEdge Reset counter on falling edge of the selected signal.
Any Edge AnyEdge
Reset counter on the falling or rising edge of the selected
signal.
Counter Duration counterDuration Sets the duration (or number of events) before the
CounterEnd event is generated.
DFNC
Counter Value counterValue Read the current value of the selected counter. (RO)
Counter Value At Reset counterValueAtReset
Reads the value of the selected counter when it was reset
by a trigger or by an explicit Counter Reset command.
DFNC
Counter Reset counterReset Resets the selected counter to zero. The counter starts
immediately after the reset. To temporarily disable the
counter, set the Counter Event Source feature to Off.
(WO)
DFNC
Timer Selector timerSelector Selects which timer to configure.
DFNC
Timer Mode timerMode
Select the timer mode. The selected Timer is Active or
Disabled. When Disabled, the Timer can be configured.
DFNC
Off Off The selected Timer is Disabled.
The selected Timer is Enabled.
Timer Status timerStatus Returns the current state of the timer. (RO)
DFNC
Timer Idle TimerIdle The timer is idle. The CounterStartSource feature is
The timer is waiting for a start trigger.
Timer Delaying TimerDelaying The timer is counting the requested delay.
The timer is counting for the specified duration.
Timer Completed TimerCompleted The timer reached the TimerDuration count.
